Double Flange Triple Offset Butterfly Valve

Double Flange Triple Offset Butterfly Valve — PVPeW 2026

Description

A butterfly valve for industrial flow-control applications. Key specifications: Nominal Diameter: DN50; Pressure Rating: PN10 / Class150; Body Material: WCB / CF8 / CF3M / CF3; Trim Material: PTFE / PPL; Connection Type: Flanged; Temperature Range: 538℃; Applicable Standard: API609 / EN593 / EN12569 / ANSI B16.10 / ASME B16.5 / ASME B16.47 / EN 1092 / ISO 7005 / JIS B2220 / GB/T 9124.1; Certification: Ce / ce; SeatLeakageTest: 1.1; AirTightnessTest: 0.6; Model: D343H-16; D343W-16P: D343W-16R; WorkingPressure(MPa): 1.6; ApplicableMedia: Water / oil / or non-corrosive media; Nitricacidmedia: Acetic acid media; Stem: 2Cr13; BodySealingSurface: Hardfaced with Alloy 507; DiscSealingSurface: 304 + Flexible Graphite; 304+PTFE: 304 + PTFE; Packing: Flexible Graphite; PTFE: PTFE; 150LB: 2; 300LB: 2; Keyword: Double Flange Triple Offset Butterfly Valve; SizeRange: NPS 2"~NPS 160" (DN50~DN4000) Rating: Class 150~Class1500 (PN10~PN250) Body Material: Carbon Steel / Stainles; Keywords: Double Flange Triple Offset Butterfly Valve.
